AEM EMS-4 Universal Programmable Engine Management System

Description

OVERVIEW
AEM’s EMS-4 Universal Standalone Programmable Engine Management System is the ideal standalone Engine Management System for modified Powersports and four-cylinder race car applications. The EMS-4 was created using AEM’s powerful Series 2 hardware and includes all of its advanced features without the unneeded ancillary components.

WHY YOU WANT THIS
If you have modified your four-cylinder Powersports application beyond the factory ECU’s ability to control engine operation, or have a 4-cylinder race vehicle that does not require some of the advanced hardware features of an AEM Series 2 Plug & Play System, AEM’s EMS-4 provides complete engine control for the maximum power and reliability.

THE HARDWARE
AEM’s EMS-4 provides complete engine control for small engines with up to 4 cylinders. The unit includes a 36-pin connetor that is specifically designed to operate in harsh environments. It is completely sealed and weather/shock proof, allowing it to be mounted anywhere. The EMS-4 works with MAG or HALL crank inputs and can directly drive smart coils or an external ignitor such as AEM’s 4-Channel Coil Driver

KEY FEATURES

• 4 Saturated Injector Drivers
• 4 Coil Triggers
• 8 General Purpose Inputs/Outputs
• Mag or Hall Cam and Crank Inputs
• O2 Input
• Knock Input
• 8 MB Internal Data Logger
• VSS Hall Input
• Can Data Stream
• USB Comm Port
• Compact (4.8″ x 4.55″ x 1.44″), weather/shock proof enclosure
• Utilizes AEMTuner Interface Software
• System is fully enabled and unlocked – Never pay for Upgrades
• Context Sensitive Help Eases Tuning Process
• Maps can be Password Protected by the Tuner to Prevent Unauthorized Usage Sharing
• Data analysis using AEMdata software.
